New Arrival !! Amlogic S905 Combo Android TV Receiver HD Android DVB S2+DVB T2 Combo tv box

FOB Reference Price:Get Latest Price
$1.00 - $50.00 / Pieces | 1 Piece/Pieces Order price: Much Cheap (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
VS
Model Number:
VS-K1 plus
CPU:
AMlogic S905Quad-core 64-bit ARM-A53 up to 2GHz
Memory:
DDRIII 1GB/2GB
Flash:
Nand Flash 8GB
OS:
Google Android 5.1.1
WiFi:
802.11 b/g
RJ45:
100M Ethernet
TV receiver option:
DVB-T2//DVB-S2
PVR:
Supports PVR recording
EPG:
7 days EPG
Supply Ability
Supply Ability:
300000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Physical Specification
Unit dimension: 130*120*32MM
Giftbox dimension:157*157*82mm
Carton Package: 425*325*330mm
20pcs/ctn
Unit G.W:0.6g
Port
HK/SHENZHEN

Advantage :





Technical Customized :





A, Source Code Open



B, Customized Clients LOGO On housing and pacakge ,



C, Customized LOGO on device booting



D, Optimizing Customized Launcher and New Design



E, Engineer technical supports and Communication in person (Shenzhen or Your Office )





  Note:  (This Model present we not accept buying for personal use customers , We only accept OEM order or Wholesles or distributor , For Personal use end user please search on Aliexpress . If you buy for personal use Maybe I not reply you email . Thanks for your understand  )













Android quad core By Amlogic S905 CPU ,

1GB RAM +8GB flash

With DVB T2/S2/ATSC/ISDB-T/DTMB tv receive









 DVB S2  Spec :





DVB S2DVB-S2 system standard:ETS 302 307
Symbol Rates: QPSK,8PSK
Forward error correction rate 1/4,1/3,2/5,3/5,2/3,3/4,4/5,5/6,8/9,9/10
Carrier frequency acquisition range: ±5MHz for symbol rates above 3 Msps and ±3MHz for the remaining symbol rates
Roll-off factors for pulse shaping: 0.2, 0.25 and 0.35
Symbol Rates: 1- 55 Msps
Code Rates: 1/2, 2/3, 3/4, 5/6, 7/8
Input Signal level: -84 dBm to 0 dBm (average power)
ANT. Connector:IEC TYPE, female Loop Outpur:IEC TYPE, male





DVB-T2DVB-T2 system standard:ETSIEN 302 755
Support MPLP
Demodulation: QPSK,16QAM,64QAM or 256QAM
Forward error correction rate 1/2,2/3,3/4,3/5,5/6
Guard interval :1/4,19/256,1/8,19/128,1/16,1/32,1/128
Bandwith: 6/7/8MHz
Input Frange range:54--860MHz Input Impedance:75 Ω
Input Signal level: -84 dBm to 0 dBm (average power)
ANT. Connector:IEC TYPE, female Loop Outpur:IEC TYPE, male,









Specification





Quad-core Android5.1.1 TV BOX
Hardware
CPUAmlogic S905 Quad-core 64-bit ARM® ™-A53 up to 2GHz
GPUPenta-core ARM® Mali™-450
3D GraphicsOpenGL ES 1.1/2.0 and Open VG 1.1 support
Video UHD 4K 60fps HW decoding, supports multiple formats including H.265 10-bit, H.264 and AVS+FHD 1080p 60fps HW encoding, supports H.264
RAMDDRIII 1GB
ROMNand Flash 8GB ( 4~32GB Optional  )
WiFiBuilt in 2.4G WiFi,
BlutoothOptional
IRInfra Remote control
LED IndicatorPower ON :blue; Standby :Red
MouldPrivate Tooling
3GSupport most external 3G USB dongle
 HDMI 2.04K 2K HDMI2.0 , HDCP2.2
4*USB HOST4 High speed USB 2.0,support U DISK and USB HDD
1*TF CARDSupport 1~32GB
1*AV  AV output
1*SPDIFAudio output
1*RJ4510/100 BaseT,
PowerDC Adapter ( 12V/1A)
DVBDVB-T2 / DVBS2  / ISDB-T / DTMB / ATSC( OPTION)
AccessoriesAdapter
Gift Box
IR remote control
HDMI Cable
User Manual
Software
OSAndroid 5.1.1
DecoderHD MPEG1/2/4,H.265/HEVC, HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10
VideoAVI/RM/RMVB/TS/VOB/MKV/MOV/ISO/WMV/ASF/FLV/DAT/MPG/MPEG
MusicMP3/WMA/AAC/WAV/OGG/AC3/DDP/TrueHD/DTS/DTS/HD/FLAC/APE
PhotoHD JPEG/BMP/GIF/PNG/TIFF
Support LanguageChinese , English ,Germany ,Japanese, Korea  etc.  24 languages
WiFi HotpointSupport
Mouse/ KeyboardSupport mouse and keyboard via USB
Support 2.4G wireless mouse and keyboard via 2.4G USB dongle
KODISupport local high-definition play, support plug-in installation and play
DRMOptional :Microsoft Playready,Verimatrix ,Google Widevine
Otherssupport DLNA \AirPlay \Google TV Remote \LAN \Miracast \3D moive
Appliactions
OnlineBrowse all  video websites ,support  Netflix ,Hulu ,Flicker , Picasa,Youtube,Twitter ,Facebook,etc
AppsApps  download  freely form  android  market ,amazon appstore etc
MediumLocal Media playback,support HDD, U disck ,SD card
Talk onlineSupport  SKYPE video  call  , facebook ,twitter ,Netflix ,Youtube ,  etc
OthersSupport   Email , office suit etc
Loading
Loadingmachine size130*120*32MMPackaged size157*157*82mm
machine weight158gPackaged weight625g
PCS/CTN20Carton Size425*325*330mm
